PCB design is the process of creating a circuit board’s layout by placing and connecting electronic components. This involves designing the physical board’s structure and routing the electrical connections (traces) that link the components, with the goal of ensuring functionality, performance, and manufacturability. It is a multi-step process that begins with a schematic diagram and uses specialized software to define the board’s layers, component footprints, and trace paths before generating manufacturing files
